Our microdisplays deliver precision and clarity for mission-critical environments
— from weapon sights to AR HUD systems and medical imaging.
MDP02
0.61” Ultra-High-Resolution OLED Microdisplay
+ Display Size: 0.61 inch diagonal
+ Resolution:
Full Color: 1300 × 1044 (5.4M dots)
Monochrome: up to 2600 × 2088 (QSXGA-class)
+ Pixel Pitch: 9.4 µm (sub-pixel pitch 4.7 µm)
+ Brightness:
Full Color: up to 250 cd/m²
White Monochrome: up to 1,000 cd/m²
+ Contrast Ratio: Typ. 10,000:1
+ Power Consumption: ~250 mW (typical)
+ Interface: Digital RGB / Analog video (via driver boards)
+ Operating Temperature:
Commercial: –20°C to +50°C
Professional: –40°C to +70°C
MDP05
0.19” Ultra-High-Brightness Monochrome OLED Microdisplay
+ Display Size: 0.19 inch diagonal
+ Resolution: 304 x 256
+ Color Options:
Yellow Monochrome (575nm)
Red Monochrome (610 nm)
+ Pixel Pitch: 12 µm x 12 µm
+ Active Area: 3.65 mm x 3.07 mm
+ Brightness:
Regular Luminance: up to 12,000 cd/m²
High Luminance: up to 28,000 cd/m²
+ Power Consumption: ~1 mW (typical)
+ Interface: SPI
+ Operating Temperature:
Commercial: –20°C to +50°C
Professional: –40°C to +70°C
MDP07
0.38” High-Brightness Monochrome OLED Microdisplay
+ Display Size: 0.38 inch diagonal
+ Resolution:
Full Color: 873 x 500
Monochrome: 1746 x 1000
+ Pixel Pitch: 10 µm (sub-pixel pitch 5 µm)
+ Brightness: up to 18,000 cd/m² (yellow or red monochrome)
+ Contrast Ratio: Typ. 10,000:1
+ Power Consumption: ~70 mW (typical)
+ Interface: Analog RGB (digital via driver board)
+ Operating Temperature:
Commercial: –20°C to +50°C
Professional: –40°C to +70°C
MDP08
0.19” Ultra-Low-Power High-Brightness Red Monochrome OLED Microdisplay
+ Display Size: ~0.19 inch diagonal
+ Resolution: 608 x 512 (memory graphical sub-pixels)
+ Sub-Pixel Pitch: 6 µm (square sub-pixel arrangement)
+ Active Area: 3.65 mm × 3.07 mm
+ Color / Type: Red monochrome, high luminance (very high color purity)
+ Brightness:
Regular Luminance: up to 15,000 cd/m²
High Luminance: up to 20,000 cd/m²
+ Contrast Ratio: Typ. 10,000:1
+ Power Consumption: 4 mW (typical)
+ Interface: Digital SPI (no external video driver/FPGA required)
+ Architecture: Memory-type pixel addressing (no video refresh required)
+ Operating Temperature:
Commercial: –20°C to +50°C
Professional: –40°C to +70°C
MDP09
0.39” Compact SXGA AMOLED Microdisplay
+ Display Size: 0.39 inch diagonal
+ Resolution:
Full Color: 1024 × 768 (XGA)
Monochrome: up to 2088 × 1576 (SXGA-compatible)
+ Pixel Pitch: 7.6 µm (sub-pixel pitch 3.8 µm)
+ Brightness:
Full Color: up to 200 cd/m²
White Monochrome: up to 800 cd/m²
Red Monochrome: up to 8,000 cd/m²
+ Contrast Ratio: Typ. 10,000:1
+ Power Consumption: ~40 mW (typical)
+ Interface: Analog / Digital via MDM09 driver family
+ Operating Temperature:
Commercial: –20°C to +50°C
Professional: –40°C to +70°C
MDP10
0.6” SXGA OLED
Microdisplay
+ Display Size: 0.6 inch diagonal
+ Resolution:
Full Color: 1024 × 768 (XGA)
Monochrome: up to 2088 × 1576 (SXGA-compatible)
+ Pixel Pitch: 11.4 µm (sub-pixel pitch 5.7 µm)
+ Brightness:
Full Color: up to 250 cd/m²
White Monochrome: up to 1,000 cd/m²
+ Contrast Ratio: Typ. 10,000:1
+ Power Consumption: ~70 mW (typical)
+ Interface: Analog / Digital via MDM09 driver family
+ Operating Temperature:
Commercial: –20°C to +50°C
Professional: –40°C to +70°C
